| Standby Rating | kVA | 350 |
| Standby Rating | kW | 280 |
| Prime Rating | kVA | 320 |
| Prime Rating | kW | 256 |
| Frequency | Hz | 50 |
| Voltage | V | 230/400 |
| Fuel Type | Diesel | |
| Control Panel Model | Datakom D309 | |
| Cabin | AK 10 |
| Brand | CUMMINS | |
| Model | 6LTAA9.5-G1 | |
| Engine Type | 4 Stroke – Diesel | |
| Injection Type | Direct Injection | |
| Suction System | Turbo Charge | |
| Number of Cylinders | 6 | |
| Cylinder Diameter and Stroke | mm | 116×148 |
| Cylinder Volume | L | 9,5 |
| Cooling Type | Water Cooled | |
| Fuel Consumption at Stand by Load | l/h | 78 |
| 100% Fuel Consumption at Prime Load | l/h | 70 |
| 75% Fuel Consumption at Prime Load | l/h | 52 |
| 50% Fuel Consumption at Prime Load | l/h | 35 |
| Total Oil Capacity | L | 28,1 |
| Total Cooling Capacity | L | 55,5 |
| Governor Type | Type | Electronic |
| Brand | Leroy Somer | |
| Model | TAL-046-H | |
| Output Voltage | V | 230/400 |
| Frequency | HZ | 50 |
| Automatic Voltage Regulation | ±% | 1 |
| Alternator Standby Power | kVA | 400 |
| Alternator Continuous Use Power | kVA | 365 |
| Power Factor | Cosq | 0,8 |
| Number of Cables | 12 | |
| Winding Pitch | 2/3 | |
| Protection Class | IP23/H | |
| Warning System | Self-excited | |
| Execution System | Electronic AVR | |
| Performance – PF 0.8 / 75% Load | % | 92 |
Dimensions Without Canopy and Weight |
||
| Length x Width x Height | mm | 2980x1250x2100 |
| Net Weight | kg | 2650 |
| Fuel Tank Capacity | lt | 590 |
Dimensions With Canopy and Weight |
||
| Length x Width x Height | mm | 3950x1250x2450 |
| Net Weight | kg | 3045 |
| Fuel Tank Capacity | lt | 590 |
| Desibel | db(A) | 65-75 |
