| Standby Rating | kVA | 700 |
| Standby Rating | kW | 560 |
| Prime Rating | kVA | 636 |
| Prime Rating | kW | 508,8 |
| Frequency | Hz | 50 |
| Voltage | V | 230/400 |
| Fuel Type | Diesel | |
| Control Panel Model | Datakom D309 | |
| Cabin | AK 10 |
| Brand | CUMMINS | |
| Model | VTA28G5 | |
| Engine Type | 4 Stroke – Diesel | |
| Injection Type | Direct Injection | |
| Suction System | Turbo Charge & Aftercooler | |
| Number of Cylinders | 12 | |
| Cylinder Diameter and Stroke | mm | 139,7×152,4 |
| Cylinder Volume | L | 28 |
| Cooling Type | Water Cooled | |
| Fuel Consumption at Stand by Load | l/h | 154 |
| 100% Fuel Consumption at Prime Load | l/h | 140 |
| 75% Fuel Consumption at Prime Load | l/h | 104 |
| 50% Fuel Consumption at Prime Load | l/h | 73 |
| Total Oil Capacity | L | 83 |
| Total Cooling Capacity | L | 126 |
| Governor Type | Type | Electronic |
| Brand | Leroy Somer | |
| Model | TAL-047-F | |
| Output Voltage | V | 230/400 |
| Frequency | HZ | 50 |
| Automatic Voltage Regulation | ±% | 1 |
| Alternator Standby Power | kVA | 730 |
| Alternator Continuous Use Power | kVA | 660 |
| Power Factor | Cosq | 0,8 |
| Number of Cables | 12 | |
| Winding Pitch | 2/3 | |
| Protection Class | IP23/H | |
| Warning System | Self-excited | |
| Execution System | Electronic AVR | |
| Performance – PF 0.8 / 75% Load | % | 95,5 |
Dimensions Without Canopy and Weight |
||
| Length x Width x Height | mm | 3600x2100x2440 |
| Net Weight | kg | 5650 |
| Fuel Tank Capacity | lt | 1410 |
Dimensions With Canopy and Weight |
||
| Length x Width x Height | mm | 5000x2100x3150 |
| Net Weight | kg | 6200 |
| Fuel Tank Capacity | lt | 1410 |
| Desibel | db(A) | 65-75 |
